Vacuum Laminated Glass

Vacuum Laminated Glass

Insulation Vacuum Laminated Glass

Low Noise Vacuum Laminated Glass

Place of Origin:


Brand Name:




Model Number:

Vacuum Glass JY-IV117

Contact Us

Request A Quote
Product Details
Vacuum Laminated Glass
300*300mm To 1500*2500mm
Vacuum Layer Thickness:
PVB Thickness:
Glass Color:
PVB Color:
Glass Type:
LOW-E Tempered Glass,tempered Glass,laminated Glass,could Be Produced As Your Required
Thermal Insulation Performance:
0, 47W/M2.K-0.71W/M2.K
Payment & Shipping Terms
Minimum Order Quantity
1 wooden box
Packaging Details
Wooden box
Delivery Time
Payment Terms
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
Product Description

What is Vacuum Laminated Glass?

Vacuum Laminated glass is a kind of composite vacuum glass, which adopts a three-glass two-cavity structure,one layer of low-e tempered vacuum and one layer of PVB glass. On the basis of vacuum glass, the noise reduction function and safety of the glass are further enhanced through combined configuration.
Joy Shing glass factory direct sales, can produce glass thickness, size, color, composite vacuum insulating glass, vacuum insulating laminated glass, etc. according to customer requirements.Our company has rich industry experience and engineering cases, and can provide integrated glass solutions, online technical consultation, and perfect after-sales service for your projects.

Vacuum Laminated Glass 0


Product name
Vacuum Laminated Glass
Single glass thickness
PVB color green,white,clear,blue,grey,etc.
PVB thickness 0.38mm,0.76mm,1.14mm,etc.
Thickness Custom
Glass Type
LOW-E tempered glass,tempered glass,laminated glass,could be produced as your required
Mini size:300*300mm  max size:1500*2500mm Custom
Vacuum layer thickness
Composite process Insulated, laminated,etc.
Lead time

Within 15 days

25 years
Project solution
Total solution for projects, Others
Packaging Details
Sea Worthy Strong Wooden Crates

Payment Terms

30% deposit, and balance before shipment by T/T


Glass structure Type of low-e glass U Value W/m²· K SC

Solar energy

Transmittance %

Visible Light db
Transmittance % Reflectivity%
outdoor indoor
5T+0.76P+5TL+0.3V+5T single silver 0.54 0.58 0.5 76 11 12 41
double silver 0.44 0.4 0.35 65 10 12


5T: 5mm tempered glass ; 5TL: 5mm Low-e tempered glass ;0.3V: vacuum layer 0.3mm; 0.76P: 0.76mm PVB layer


Above data are for reference only. parameters for a specific product needs to be calculated separately.
For parameters related to a specific product. please refer to the data provided by Joy Shing Glass.


Advantages of vacuum laminated glass


Vacuum laminated glass has the high safety of laminated glass. When the glass is broken, the fragments will stick to the PVB film, and there will be no splashing and hurting people.

2. Insulation:

The vacuum layer effectively isolates air convection and heat transfer, and the Low-E glass significantly reduces the radiation heat transfer between two pieces of glass.The thermal insulation performance of vacuum glass is about 6-8 times that of single glass, and 4-6 times that of insulating glass


Vacuum Laminated Glass 1

3. Anti-condensation:

Due to the high heat insulation performance of vacuum glass, it is difficult to dissipate the indoor heat, and the surface temperature of the glass is higher than the dew point, so it is not easy to generate condensation.

Vacuum Laminated Glass 2

4. Low noise:

The vacuum layer of the vacuum glass effectively isolates the sound transmission. The sound insulation of single vacuum glass can reach 39dB, and the sound insulation of composite vacuum glass can reach 42dB.


Product photo

Vacuum Laminated Glass 3


Application fields of vacuum glass

Low-e Vacuum glass is widely used in many fields such as building energy saving, doors and windows, library, transportation, curtain wall, freezer, wine cabinet, solar building, etc. etc.

Vacuum Laminated Glass 4


Joy Shing Glass Co., Ltd. was founded in 2013. We are integrated in producing, selling, service providing for all kinds of custom building glass like acid etched glass, low-e glass, mirror glass, tempered glass, laminated glass, insulated glass, AR coating glass, fire-rated glass, U channel glass, PDLC smart glass, etc.

More product options
Vacuum Laminated Glass 5


Vacuum Laminated Glass 6
Vacuum Laminated Glass 7
Vacuum Laminated Glass 8Vacuum Laminated Glass 9Vacuum Laminated Glass 10
Vacuum Laminated Glass 11
Vacuum Laminated Glass 12
Vacuum Laminated Glass 13
Vacuum Laminated Glass 14
Q: What is the MOQ?
A: Generally, there is no MOQ for processed glass, but if you want to receive the best price, the bigger quantity, the better price.
Q: Can I have a small sample to verify the quality?
A: Sure, we welcome samples to be tested and checked for quality.
Q: Can I visit your factory?
A: Yes, we welcome all of the customers to visit our factory when you have real requirements, we will take you to each of our production lines, and discuss orders in our office.
Q: Do you offer a guarantee for the products?
A: Yes, generally, we offer 10 years warranty for processing glass based on your normal uses, we advise you use it in the right way can keep your product's service life a long time .
Q: How do you control the quality of your products?
A: We have standard management in the factory based on the ISO system, and train our staff regularly, our production department will choose high-quality materials for glass strictly, for finished excellent products. And we have QC for each process, once find any problem, we will replace the glass, to make sure every piece of glass go to the customer's warehouse is in good condition.
