Low-E Vacuum Glass

Low-E Vacuum Glass

Flat Low E Vacuum Glass

Anti Condensation Vacuum Glass

Place of Origin:


Brand Name:




Model Number:

Vacuum Glass JY-IV115

Contact Us

Request A Quote
Product Details
Low-e Vacuum Glass
300*300mm To 1500*2500mm
Vacuum Layer Thickness:
Glass Color:
Ultra Clear,clear
Glass Type:
LOW-E Glass,clear Glass,could Be Produced As Your Required
Thermal Insulation Performance:
0, 47W/M2.K-0.71W/M2.K
Payment & Shipping Terms
Minimum Order Quantity
1 wooden box
Packaging Details
Wooden box
Delivery Time
Payment Terms
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
Product Description

What is Low-e vacuum glass?

Low-e vacuum glass is to seal the surroundings of two pieces of flat glass, evacuate the gap and seal the exhaust hole. The minimum gap between the two pieces of glass is 0.15mm. In order to achieve better heat insulation performance, one of the glass uses Low -e glass.

Joy Shing Low-e vacuum glass has become a new generation of high-performance glass,which has the advantages of ultra-thin, heat insulation, sound insulation, anti-condensation, energy saving, and long life.

Low-E Vacuum Glass 0


Product name
Low-e Vacuum Glass
Glass Type
LOW-E glass,clear glass
Mini size:300*300mm  max size:1500*2500mm Custom
Vacuum layer thickness
Composite process Insulated, laminated
Lead time

Within 15 days

25 years
Project solution
Total solution for projects, Others
Packaging Details
Sea Worthy Strong Wooden Crates

Payment Terms

30% deposit, and balance before shipment by T/T


Glass structure U Value W/m²· K SHGC Visible Light SC LSG
Transmittance % Reflectivity%
Ext. Int.
5C+0.15V+5L 0.65 0.64 81 12 13 0.73 1.27
5C+15A+5C+0.15V+5L 0.50 0.56 74 18 18 0.65 1.31
5L+15A+5C+0.15V+5L 0.48 0.50 62 17 16 0.58 1.16

5C: 5mm clear glass ; 5L: 5mm Low-e glass ;0.15V: vacuum layer 0.15mm; 15A: 15mm argon layer


Above data are for reference only. parameters for a specific product needs to be calculated separately.
For parameters related to a specific product. please refer to the data provided by Joy Shing Glass.


Advantages of low-e vacuum glass

1. Insulation:

The vacuum layer effectively isolates air convection and heat transfer, and the Low-E glass significantly reduces the radiation heat transfer between two pieces of glass.The thermal insulation performance of vacuum glass is about 6-8 times that of single glass, and 4-6 times that of insulating glass


Low-E Vacuum Glass 1

2. Anti-condensation:

Due to the high heat insulation performance of vacuum glass, it is difficult to dissipate the indoor heat, and the surface temperature of the glass is higher than the dew point, so it is not easy to generate condensation.

Low-E Vacuum Glass 2

3. Low noise:

The vacuum layer of the vacuum glass effectively isolates the sound transmission. The sound insulation of single vacuum glass can reach 39dB, and the sound insulation of composite vacuum glass can reach 42dB.


Product photo

Low-E Vacuum Glass 3


Application fields of vacuum glass

Low-e Vacuum glass is widely used in many fields such as building energy saving, doors and windows, library, transportation, curtain wall, freezer, wine cabinet, solar building, etc. etc.

Low-E Vacuum Glass 4


Joy Shing Glass Co., Ltd. was founded in 2013. We are integrated in producing, selling, service providing for all kinds of custom building glass like acid etched glass, low-e glass, mirror glass, tempered glass, laminated glass, insulated glass, AR coating glass, fire-rated glass, U channel glass, PDLC smart glass, etc.

More product options
Low-E Vacuum Glass 5


Low-E Vacuum Glass 6
Low-E Vacuum Glass 7
Low-E Vacuum Glass 8Low-E Vacuum Glass 9Low-E Vacuum Glass 10
Low-E Vacuum Glass 11
Low-E Vacuum Glass 12
Low-E Vacuum Glass 13
Low-E Vacuum Glass 14
Q: What is the MOQ?
A: Generally, there is no MOQ for processed glass, but if you want to receive the best price, the bigger quantity, the better price.
Q: Can I have a small sample to verify the quality?
A: Sure, we welcome samples to be tested and checked for quality.
Q: Can I visit your factory?
A: Yes, we welcome all of the customers to visit our factory when you have real requirements, we will take you to each of our production lines, and discuss orders in our office.
Q: Do you offer a guarantee for the products?
A: Yes, generally, we offer 10 years warranty for processing glass based on your normal uses, we advise you use it in the right way can keep your product's service life a long time .
Q: How do you control the quality of your products?
A: We have standard management in the factory based on the ISO system, and train our staff regularly, our production department will choose high-quality materials for glass strictly, for finished excellent products. And we have QC for each process, once find any problem, we will replace the glass, to make sure every piece of glass go to the customer's warehouse is in good condition.
